8G EMMC PCB Sd Card 4mil Circuit Board Components Green ROGERS

1PCS
MOQ
USD+10-50+per pcs
Price
8G EMMC PCB Sd Card 4mil Circuit Board Components Green ROGERS
Features Gallery Product Description Request A Quote
Features
Specifications
Memory Size:: 4G RAM 8G 16G EMMC SD Support
GPIO:: 40 PIN
Memory Type:: RAM Flash SD
Base Material: FR4/ROGERS/PET/HDI/CEM/PI
Board Thickness: 0.4mm-3.2mm
Surface Finishing: HASL
Min. Line Spacing: 3 Mil (0.075 Mm)
Min. Line Width: 4mil
Min. Hole Size: 4mil
Copper Thickness: 1/2OZ 1OZ 2OZ 3OZ
Type: Electronic Board
Solder Mask: Green. Red. Blue. White. Black.Yellow
Material: FR4 CEM1 CEM3 Hight TG
Color: Blue,yellow,Green/White
Layer: 1-40 Layer
High Light:

PCB Sd Card 4mil

,

4mil Circuit Board Components

,

ROGERS Circuit Board Components

Basic Infomation
Place of Origin: Guangdong, China
Brand Name: GW-PCBA
Certification: ISO9001, ISO14001, TS16949, ROHS, CE
Model Number: PCBA-2025
Payment & Shipping Terms
Packaging Details: Inner packing: Anti-static vaccum bag Outer packing: High quality carton
Delivery Time: PCB 3-7dyas, PCBA 1-3weeks/1 - 1000 -15days;1001 - 5000-20days;5001 - 20000-35days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 30000 Square Meter/Square Meters per Month module electronic board
Product Description
ProfessionalElectronic Components Integrated Circuit 8G EMMC Flash Memory Support SD PCB Board

1. Products Description
Model
BPI-M3
Brand
BPI
Input voltage
5V/2A
Type
integrated circuit
The Products is a super charged single board computer with an Octa-core processor and 2GB of RAM. Along side the elite processing unit, it features Gigabit Ethernet, 2 USB, SATA, WiFi, BT, and HD MI connection. It can run on a variety of operating systems including Android, Lubuntu, Ubuntu, Debian, and Raspbian.
Being a brother of the power hungry M2, the M3 does not want to rest while his brother goes to acquire two more cores. The M3 secretly mastered the powerful art of Octa-core to best even the M2. Unlike his careless brother, the M3 did not lose his SATA port.

Key Features:
* Allwinner A83T Octa-core 1.8GHz Powerful CPU.
* 2 GB LPDDR3 memory.
* 8 GB eMMC storage.
* HD MI out
* IR control
* WiFi & BT onboard.
* MIPI DSI ingerface
* CSI camera interface

2. Our Services



1. PCB fabrication.

2. Turnkey PCBA: PCB+components sourcing+SMD and through-hole assembly

3. PCB clone, PCB reverse engineering.

PCB or PCBA Files Requests:


1. Gerber files of the bare PCB board
2. BOM (Bill of material) for assembly (please kindly advise us if there is any acceptablecomponents substitution.)
3. Testing Guide & Test Fixtures if necessary
4. Programming files & Programming tool if necessary
5. Schematic if necessary



3. Company Information



Global Well Electronic Inc. is a professional PCB solution supplier from Shenzhen, China, integrating PCB circuit board production and processing, STM processing and mounting, PCBA OEM, component purchasing, PCB/PCBA custom design-production- A comprehensive PCB circuit board company with one-stop turnkey service of processing-assembly-finished products. The company has a strong supply chain system, a professional and efficient collaborative team, a sound and complete quality control system, and the business philosophy of honesty and trustworthiness, customer first, and presents the products to everyone with low prices, reliable quality, high-quality service and after-sales service. client.

We provide total PCB solutions from PCB design to final mass production, including PCB fabrication and assembly, component sourcing, solder paste stencils, conformal coatings, and more. Serving the global electronics field, including industrial control, medical electronics, military equipment, power communication, automotive electronics, AI artificial intelligence, smart home and other industries.



8G EMMC PCB Sd Card 4mil Circuit Board Components Green ROGERS 0



Our factory located in Shenzhen, and have almost 300

employees, more than 30 production lines include SMT, DIP, automatic welding, aging test and assembly. We have SMT machines from Japan and Korea, automatic solder paste printing machines, solder paste inspection machine(SPI)12 temperature zone reflow soldering machine, AOI detector, X-RAY detector, wave soldering machine, EM PCB ,dispenser,laser print machine etc., Different line configurations can meet requirements from small sample order to bulk shipment.



Our company has obtained ISO 9001 quality system certification and ISO 14001 system certification. With multi-testingprocedures, our products carry out the quality system standard strictly.



4. Main Equipment:



8G EMMC PCB Sd Card 4mil Circuit Board Components Green ROGERS 1

8G EMMC PCB Sd Card 4mil Circuit Board Components Green ROGERS 2



5.PCB Technical Specification



(1) PCB Technical Specification

Order Quantity 1-300,000,30000 Square Meter/Square Meters per Month module electronic board
Layer 1,2,4,6,upto 24 layer
Material FR-4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc
PCB type Rigid,flexible,rigid-flexible
Shape Any shape: Rectangular,round,slots,cutouts,complex,irregular
Max PCB dimensions 20inch*20inch or 500mm*500mm
Thickness 0.2~4.0mm, Flex 0.01~0.25''
Thickness tolerance ± 10%
Copper thickness 0.5-4 oz
Copper thickness tolerance ± 0.25oz
Surface finish HASL,Nickle,Imm Gold,Imm Tin,Imm Silver,OSP etc
Solder mask Green, red,white,yellow,blue,black, Double-sided
Silk screen White,yellow,black,or negative, Double-sided or single-sided
Silk screen min line width 0.006'' or 0.15mm
Min drill hole diameter 0.01'',0.25mm.or 10 mil
Min trace/gap 0.075mm or 3mil
PCB cutting Shear,V-score,tab-routed



(2) Turnkey PCBA Capabilities



Turnkey PCBA PCB+components sourcing+assembly+package
Assembly details SMT and Thru-hole, ISO lines
Lead Time Prototype: 15 work days. Mass order: 20~25 work days
Testing on products Flying Probe Test, X-ray Inspection, AOI Test, functional test
Quantity Min quantity: 1pcs. Prototype, small order, mass order, all OK
Files we need PCB: Gerber files(CAM, PCB, PCBDOC)
Components: Bill of Materials(BOM list)
Assembly: Pick-N-Place file
PCB panel Size Min size: 0.25*0.25 inches(6*6mm)
Max size: 20*20 inches(500*500mm)
PCB Solder Type Water Soluble Solder Paste, RoHS lead free
Components details Passive Down to 0201 size
BGA and VFBGA
Leadless Chip Carriers/CSP
Double-sided SMT Assembly
Fine Pitch to 0.8mils
BGA Repair and Reball
Part Removal and Replacement
Component package Cut Tape,Tube,Reels,Loose Parts
PCBA process

Drilling-----Exposure-----Plating-----Etaching

Stripping-----Punching-----Electrical Testing-----SMT-----Wave

Soldering-----Assembling-----ICT-----Function Testing-----Temperature - Humidity Testing




6. PCB&PCBA Products Show



8G EMMC PCB Sd Card 4mil Circuit Board Components Green ROGERS 3



7. Certifications



8G EMMC PCB Sd Card 4mil Circuit Board Components Green ROGERS 4



8. Packaging & Shipping



Packing details:

PCBA are packed into plastic bags. Plastic bags are put into small carton. 4 small carton into a big carton.

A big carton: 35×32×40 cm size.



Shipping Express:

FedEx, DHL, UPS, TNT, EMS, private lines, etc.

Air freight, Sea shipping


8G EMMC PCB Sd Card 4mil Circuit Board Components Green ROGERS 5

If you need help on PCB layout, you can contact us and send the board to us. We also provide Reverse Engineering Service.

We have been providing PCB Manufacture for many years in China,and we have rich experience in product production and product assembly.We believe our team will provide high quality and low cost service for you.

Thank you very much for all your support .

Best Regareds.



9. FAQ:



Q: What files do you use in PCBA fabrication?

A: Gerber or Eagle, BOM listing, PNP and Components Position



Q:Is it possible you could offer sample?

A: Yes, we can custom you sample to test before mass production



Q: When will I get the quotation after sent Gerber, BOM and test procedure?

A: Within 6 hours for PCB quotation and around 24 hours for PCBA quotation.



Q: How can I know the process of my PCBA production?

A: 7-10 days for PCB production and components purchasing, and 10 days for PCB assembly and Testing



Q: How can I make sure the quality of my PCBA?

A: We ensure that each piece of PCBA products work well before shipping. We'll test all of them according to your test procedure. Also if there are any defect items during the shipping, we also can be free to repair for you.
