2 Layer Custom Copper LED PCB for Car Lighting with 1-3oz Copper Thickness and 0.8-1.6mm Board Thickness

2 Layer Custom Copper LED PCB for Car Lighting with 1-3oz Copper Thickness and 0.8-1.6mm Board Thickness

  • Highlight

    2 Layer LED PCB

    ,

    1-3oz Copper Thickness Aluminum PCB Board

    ,

    0.8-1.6mm Board Thickness LED Circuit Board

  • Type
    Aluminum PCB
  • Base Material
    Aluminum Base
  • Copper Thickness
    1-3oz
  • Board Thickness
    0.8-1.6mm
  • Min Hole Size
    0.2mm
  • Min Line Width
    0.1mm
  • Min Line Spacing
    0.1mm
  • Surface Finishing
    HASL OSP ENIG
  • Number Of Layers
    1layer
  • Solder Mask Color
    White Black Green Blue Red,etc.
  • Finished Board Thickness
    0.1mm-4.0mm
  • Board Thickness Tolerance
    ±10%
  • Copper Plating Hole
    18-40 Um
  • Impedance Control
    ±10%
  • Warp & Twist
    0.70%
  • Place of Origin
    Guangdong, China
  • Brand Name
    HS
  • Certification
    CE UL ROHS ISO9001
  • Model Number
    led smd pcb board
  • Minimum Order Quantity
    2
  • Price
    $222

2 Layer Custom Copper LED PCB for Car Lighting with 1-3oz Copper Thickness and 0.8-1.6mm Board Thickness

2Layer Custom Copper LED PCB for Car Lighting
LED Light PCB Circuit Board
High-quality aluminum PCB board and LED SMD PCB board for automotive lighting applications.
Custom Manufacturing Capabilities
  • 1-12 layer FR4 PCB
  • 1 layer Aluminum PCB
  • 1-4 layer Flexible PCB
  • 1-3oz copper thickness
  • 0.2mm hole size
  • 0.1mm track width/space
  • SMT PCBA service available
Frequently Asked Questions
Q: Can I have a sample to test?
A: Yes, we can send you samples to test.
Q: What specifications do you need for PCB quotation?
A: We need your PCB Gerber file, board thickness, copper thickness, surface finishing and quantity to provide an accurate quote.
Q: What is the lead time?
A: Samples require 3-5 days, mass production needs 7-10 days, depending on order volume.
Q: Do you have MOQ limit?
A: No minimum order quantity - we accept orders starting from 1 piece.
Q: Can you offer the best price for us?
A: Yes, as a specialized PCB manufacturer, we offer competitive pricing lower than trading companies.
Q: How do you ship the goods and how long does it take to arrive?
A: We ship via DHL, UPS, FedEx and TNT, with delivery typically taking 3-5 days.
Q: What are the payment terms?
A: We accept Paypal, Western Union and T/T Bank transfers.
Q: Can we visit your factory?
A: Yes, we welcome factory visits and will guide you through our production facilities.
Manufacturing Capabilities
Item Manufacture Capability
Material FR4, CEM-1, Aluminium, Polyamide
Layer No. 1-12
Finished board thickness 0.1 mm-4.0mm
Board Thickness Tolerance ±10%
Copper thickness 0.5 OZ-3OZ (18 um-385 um)
Copper Plating Hole 18-40 um
Impedance Control ±10%
Warp & Twist 0.70%
Peelable 0.012"(0.3mm)-0.02'(0.5mm)
Min Trace Width 0.075mm (3mil)
Min Space Width 0.1mm (4 mil)
Min Annular Ring 0.1mm (4 mil)
SMD Pitch 0.2 mm(8 mil)
BGA Pitch 0.2 mm (8 mil)
Min Solder Mask Dam 0.0635 mm (2.5mil)
Solder mask Clearance 0.1mm (4 mil)
Min SMT Pad spacing 0.1mm (4 mil)
Solder Mask Thickness 0.0007"(0.018mm)
Min Hole size (CNC) 0.2 mm (8 mil)
Min Punch Hole Size 0.9 mm (35 mil)
Hole Size Tolerance PTH:±0.075mm; NPTH: ±0.05mm
Hole Position Tolerance ±0.075mm
Plating HASL, Lead free HASL, Immersion Gold, OSP
Certificates ROHS, ISO9001:2008, SGS, UL certificate
