LM561C LED Aluminum PCB with 1-3oz Copper Thickness 0.8-1.6mm Board Thickness and 0.2mm Min Hole Size for Plant Lamp
-
Highlight
1-3oz Copper Thickness Aluminum LED PCB
,0.8-1.6mm Board Thickness LED Circuit Board
,0.2mm Min Hole Size LM561C LED PCB
-
Base MaterialAluminum Base
-
Copper Thickness1-3oz
-
Board Thickness0.8-1.6mm
-
Min Hole Size0.2mm
-
Min Line Width0.1mm
-
Min Line Spacing0.1mm
-
Surface FinishingHASL OSP ENIG
-
Number Of Layers1layer
-
Solder Mask ColorsWhite Black Green Blue Red,etc.
-
Min Trace Width0.075mm
-
Min Space Width0.1mm
-
Min Annular Ring0.1mm
-
SMD Pitch0.2mm
-
BGA Pitch0.2mm
-
Hole Size TolerancePTH:±0.075mm; NPTH:±0.05mm
-
Place of OriginGuangdong, China
-
Brand NameHS
-
CertificationCE UL ROHS ISO9001
-
Model Numberaluminum PCB
-
Minimum Order Quantity1
LM561C LED Aluminum PCB with 1-3oz Copper Thickness 0.8-1.6mm Board Thickness and 0.2mm Min Hole Size for Plant Lamp
LM561C LED Aluminum PCB for Plant Lamp
Custom PCB Manufacturing Services
- 1-12 layer FR4 PCB
- 1 layer Aluminum PCB
- 1-4 layer Flexible PCB
- 1-3oz copper thickness
- 0.2mm hole size
- 0.1mm track width/space
- SMT PCBA service
Frequently Asked Questions
Can I have a sample to test?
Yes, we can send you samples to test.
What specifications do you need for PCB quotation?
We need your PCB Gerber file, board thickness, copper thickness, surface finishing and quantity to quote you.
What is the lead time?
Samples need 3-5 days, mass production needs 7-10 days, also according to the order volume.
Do you have MOQ limit?
Even 1 piece, we care.
Can you offer the best price for us?
Yes, we are specialized PCB manufacturer directly, we can offer lower price than any trading company.
How do you ship the goods and how long does it take arrival?
We usually ship by DHL, UPS, FedEx and TNT. It takes 3-5 days to arrive.
What are the payment terms?
You can pay us with Paypal, Western Union and T/T Bank.
Can we visit your factory?
Yes, welcome to visit our factory anytime, and we will lead you to visit our factory and our production line.
Manufacturing Capability
| Item | Manufacture Capability |
|---|---|
| Material | FR4, CEM-1, Aluminium, Polyamide |
| Layer No. | 1-12 |
| Finished board thickness | 0.1 mm-4.0mm |
| Board Thickness Tolerance | ±10% |
| Cooper thickness | 0.5 OZ-3OZ (18 um-385 um) |
| Copper Plating Hole | 18-40 um |
| Impedance Control | ±10% |
| Warp&Twist | 0.70% |
| Peelable | 0.012"(0.3mm)-0.02'(0.5mm) |
| Min Trace Width | 0.075mm (3mil) |
| Min Space Width | 0.1mm (4 mil) |
| Min Annular Ring | 0.1mm (4 mil) |
| SMD Pitch | 0.2 mm(8 mil) |
| BGA Pitch | 0.2 mm (8 mil) |
| Min Solder Mask Dam | 0.0635 mm (2.5mil) |
| Solder mask Clearance | 0.1mm (4 mil) |
| Min SMT Pad spacing | 0.1mm (4 mil) |
| Solder Mask Thickness | 0.0007"(0.018mm) |
| Min Hole size (CNC) | 0.2 mm (8 mil) |
| Min Punch Hole Size | 0.9 mm (35 mil) |
| Hole Size Tolerance | PTH:±0.075mm; NPTH: ±0.05mm |
| Hole Position Tolerance | ±0.075mm |
| Plating | HASL: 2.5um Lead free HASL: 2.5um Immersion Gold: Nickel 3-7um Au:1-5u'' OSP: 0.2-0.5um |
| Panel Outline Tolerance | CNC: ±0.125mm, Punching: ±0.15mm |
| Beveling | 30°45° |
| Gold Finger angle | 15° 30° 45° 60° |
| Certificate | ROHS, ISO9001:2008, SGS, UL certificate |
