OEM FR4 PCBA Fabrication Multilayer PCB Assembly SMT DIP Double Side Circuit Board
-
Highlight
OEM FR4 PCBA Fabrication
,DIP double side Circuit Board
,OEM Multilayer PCB Assembly
-
Min. Trace Width/Spacing0.1mm/0.1mm
-
ApplicationConsumer Electronics, Industrial Control, Medical Equipment, Automotive, Telecommunication
-
Copper Thickness0.5oz-6oz
-
MaterialFR4
-
Lead Time1-3 Weeks
-
Max. Panel Size600mm X 1200mm
-
Board Thickness0.2mm-7.0mm
-
Surface FinishHASL, ENIG, OSP, Immersion Silver, Immersion Tin
-
Min. Hole Size0.2mm
-
Brand NameHansion
-
Model NumberFR4 double side PCBA
-
Minimum Order Quantity1
-
Price5
-
Packaging Detailsfoam+custom box
-
Delivery Time3-5days
-
Payment TermsWestern Union,T/T
-
Supply Ability10000PCS per month
OEM FR4 PCBA Fabrication Multilayer PCB Assembly SMT DIP Double Side Circuit Board
OEM PCBA Fabrication One-Stop Service Multilayer PCB Assembly SMT DIP double side Circuit Board
PCBA Manufacturing Capabilies
|
Regular delivery time
|
PCBA welding type
|
Daily capacity
|
|
· Routine proofing (within 50pcs) :
3 days for all materials
· Small batch (50-500pcs) : 3-5 days
· Batch (≥500pcs) : 5-7 days
|
· Surface Patch (PCBA)
· Plug-in post welding (THT)
|
· PCBA patch 4 million points/day
· Plug-in post welding 500,000 points/day
|
|
Ball parts (bga) spacing
|
Minimum order quantity
|
Part mounting accuracy (100FP)
|
|
· Not less than 0.25mm
· Three anti-paint spraying
|
· 1 set of stickers
|
· The whole mounting accuracy is 0.0375mm
|
|
PCBA circuit board size
|
Type of PCBS that can be affixed
|
Component size
|
|
· Small plate size: 45mm x 45mm
(Less than this size needs to be assembled)
· Large board size: 400mm x 1200mm
|
· PCB hard board (FR-4, metal substrate)
· PCB soft board (FPC)
· Soft and hard combined PCB
· Aluminum substrate
|
· Passive components: Mount 01005 (0.4mm * 0.2mm), 0201
· High precision IC such as BGA: Support X-ray to detect Min0.25mm
Spacing of BGA elements
|
|
Ball parts (bga) spacing
|
Component service
|
|
|
· Not less than 0.25mm
· Three anti-paint spraying
|
· Full set of substitutes
· Partial substitution
· Foundry only
|
FAQ
Q1: Are you a factory?
A1:Yes, we are a factory with 15 years of experience in manufacturing High Layer HDI PCBs. You can learn more about us through: 1. Factory certifications 2. 3D VR tour of our factory 3. Our products on Alibaba 4. Invitation to visit our factory 5. UL certificate number
Q2: What are your main products?
A2: We specialize in multi-layer HDI boards, high-frequency and high-speed boards, 10-40 layer PCBs, and custom technical boards.
Q3: What about pricing?
A3: We offer competitive pricing based on order volume, with discounts available. We also provide a clear breakdown of cost structures to ensure value for money.
Q4: How do you ensure on-time delivery?
A4: Our efficient supply chain ensures 99% on-time delivery for quick-turn orders and 90% for standard orders, outperforming most competitors.
Q5: How is the quality of your products?
A5: Our products meet all safety and eco-friendly standards. With 30 QC staff and 20 quality check steps, we guarantee 100% compliance with customer requirements.
Q6: What certifications do you have?
A6: We hold all major PCB certifications, except IPC 6012/IPC 6013.
Q7: What is your after-sales policy?
A7: We offer a 1-year 100% after-sales service from the date of delivery.
Q8: How well-known is your brand?
A8: We focus on building brand awareness through social media and cross-border e-commerce platforms.
