500mm Rigid Flex Circuit Boards 5oz

USD+5-15+per pcs
500mm Rigid Flex Circuit Boards 5oz
Features Gallery Product Description Request A Quote
Type:: Ceramic PCB
Place Of Origin:: Guangdong, China
Material:: FR4/CEM-1/CEM-3/FR1/aluminum
Base Material:: FR4/aluminum/ceramic
Copper Thickness:: 3oz
Board Thickness:: 2mm
Min. Hole Size:: 4mil
Min. Line Width:: 4mil
Min. Line Spacing:: 4mil
Layer: 1-40 Layer
Surface Finishing:: HASL
Color:: Green Blue Black Red White
Solder Mask:: White Black Green Blue
Testing:: 100%E-Testing
High Light:

500mm Ceramic PCB


500mm Rigid Flex Circuit Boards


5oz Rigid Flex Circuit Boards

Basic Infomation
Place of Origin: Guangdong, China
Brand Name: GW-PCBA
Certification: ISO/TS16949/RoHS/TS16949
Model Number: PCBA-1101
Payment & Shipping Terms
Packaging Details: PCB: Vacuum Packing with Carton Box PCBA: ESD Packing with Carton Box
Delivery Time: PCB 3-7dyas, PCBA 1-3weeks
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 30000 Square Meter/Square Meters per Month module electronic board
Product Description

High Quality PCBA Circuit Board Assembly Professional Rigid Pcb Flexible Aluminum Ceramic PCB

Technical Advantages of Ceramic PCB

With the development of high-power electronic products in the direction of miniaturization and high-speed, traditional FR-4, aluminum substrate, and other substrate materials are no longer suitable for the development of the pcb industry toward high-power and smart applications. With the development of science and technology, the traditional LTCC and DBC technologies are gradually being replaced by DPC and LAM technologies. The laser technology represented by LAM technology is more in line with the high-density interconnection of printed circuit boards and the development of refinement. Laser drilling is currently the front-end and mainstream technology in the PCB industry. It is efficient, fast, accurate, and has great application value. Rayming ceramic circuit boards are made by laser rapid activation metallization technology. The bonding strength between the metal layer and the ceramic is high, the electrical properties are good, and it can be repeatedly welded. The thickness of the metal layer is adjustable within 1μm-1mm, and the L/S resolution can reach 20μm. The through-hole connection can be directly realized, providing customers with customized solutions.

Through the laser drilling process, the ceramic circuit board has the advantages of high ceramic and metal bonding, no shedding, blistering, etc., to achieve the effect of growing together, high surface flatness, and roughness between 0.1μm and 0.3μm. Laser drilling hole diameter is 0.15mm-0.5mm, or even 0.06mm.
