6oz PCB Circuit Board

6oz PCB Circuit Board

  • High Light

    6oz Heavy Copper PCB

    ,

    PCB Circuit Board Fr4

    ,

    PCB Circuit Board 6oz

  • Type
    Power Bank PCBA
  • Place Of Origin
    Guangdong, China
  • Base Material
    FR4
  • Substrates Material
    Aluminum, FR-4,Rogers,CEM-1,Taconic,ceramic
  • SSupplier Type
    OEM/ODM
  • Copper Thickness
    0.5-5 OZ
  • Min. Hole Size
    0.15-0.2mm
  • Min. Line Width
    0.05mm/2mil
  • Min. Line Spacing
    3mil
  • Layer
    1-40 Layer
  • Surface Finishing
    HAL, HASL Lead Free
  • PCB Assembly Process
    TF Card Slot
  • Solder Mask
    Green. Red. Blue. White. Black
  • Testing Service
    100% AOI Testing, 100% ET Testing,100% FQC
  • MOQ
    1PCS
  • Place of Origin
    Guangdong, China
  • Brand Name
    GW-PCBA
  • Certification
    ISO/TS16949/RoHS/TS16949
  • Model Number
    PCBA-1010
  • Minimum Order Quantity
    1PCS
  • Price
    USD+0.1-15+per pcs
  • Packaging Details
    Vacumn packing for bare board, standand cartons outside for shipping.
  • Delivery Time
    PCB 3-7dyas, PCBA 1-3weeks
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    30000 Square Meter/Square Meters per Month module electronic board

6oz PCB Circuit Board

Factory Professional Promotion Heavy Copper Pcb 6oz Copper Fr4 High Tg Power Bank Pcb Circuit Board

PCB advantages:

  • R&D team support
  • UL, RoHS,ISO9001,SGS
  • IPC class2
  • Advanced production line and promtly delivery.
  • Honest Credibility in China.
  • Professional and abundant experience in PCB
  • Competitive price and good quality.
  • Excellent after-sales service



PCB showcase:

6oz PCB Circuit Board 0



Our Services

1. PCB fabrication.

2. Turnkey PCBA: PCB+components sourcing+SMD and through-hole assembly

3. PCB clone, PCB reverse engineering.
6oz PCB Circuit Board 1

6oz PCB Circuit Board 2


PCB or PCBA Files Requests:


1. Gerber files of the bare PCB board
2. BOM (Bill of material) for assembly (please kindly advise us if there is any acceptablecomponents substitution.)
3. Testing Guide & Test Fixtures if necessary
4. Programming files & Programming tool if necessary
5. Schematic if necessary

6oz PCB Circuit Board 3

Company Information

Global Well Electronic Inc. is a professional PCB solution supplier from Shenzhen, China, integrating PCB circuit board production and processing, STM processing and mounting, PCBA OEM, component purchasing, PCB/PCBA custom design-production- A comprehensive PCB circuit board company with one-stop turnkey service of processing-assembly-finished products. The company has a strong supply chain system, a professional and efficient collaborative team, a sound and complete quality control system, and the business philosophy of honesty and trustworthiness, customer first, and presents the products to everyone with low prices, reliable quality, high-quality service and after-sales service. client.

We provide total PCB solutions from PCB design to final mass production, including PCB fabrication and assembly, component sourcing, solder paste stencils, conformal coatings, and more. Serving the global electronics field, including industrial control, medical electronics, military equipment, power communication, automotive electronics, AI artificial intelligence, smart home and other industries.

6oz PCB Circuit Board 4

6oz PCB Circuit Board 5

Our factory located in Shenzhen, and have almost 300 employees, more than 30 production lines include SMT, DIP, automatic welding, aging test and assembly. We have SMT machines from Japan and Korea, automatic solder paste printing machines, solder paste inspection machine(SPI)12 temperature zone reflow soldering machine, AOI detector, X-RAY detector, wave soldering machine, EM PCB ,dispenser,laser print machine etc., Different line configurations can meet requirements from small sample order to bulk shipment.

Our company has obtained ISO 9001 quality system certification and ISO 14001 system certification. With multi-testingprocedures, our products carry out the quality system standard strictly.

Main Equipment:

6oz PCB Circuit Board 6

6oz PCB Circuit Board 7

6oz PCB Circuit Board 8



PCB Technical Specification

(1) PCB Technical Specification

Order Quantity 1-300,000,30000 Square Meter/Square Meters per Month module electronic board
Layer 1,2,4,6,upto 40 layer
Material FR-4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc
PCB type Rigid,flexible,rigid-flexible
Shape Any shape: Rectangular,round,slots,cutouts,complex,irregular
Max PCB dimensions 20inch*20inch or 500mm*500mm
Thickness 0.2~4.0mm, Flex 0.01~0.25''
Thickness tolerance ± 10%
Copper thickness 0.5-4 oz
Copper thickness tolerance ± 0.25oz
Surface finish HASL,Nickle,Imm Gold,Imm Tin,Imm Silver,OSP etc
Solder mask Green, red,white,yellow,blue,black, Double-sided
Silk screen White,yellow,black,or negative, Double-sided or single-sided
Silk screen min line width 0.006'' or 0.15mm
Min drill hole diameter 0.01'',0.25mm.or 10 mil
Min trace/gap 0.075mm or 3mil
PCB cutting Shear,V-score,tab-routed

(2) Turnkey PCBA Capabilities

Turnkey PCBA PCB+components sourcing+assembly+package
Assembly details SMT and Thru-hole, ISO lines
Lead Time Prototype: 15 work days. Mass order: 20~25 work days
Testing on products Flying Probe Test, X-ray Inspection, AOI Test, functional test
Quantity Min quantity: 1pcs. Prototype, small order, mass order, all OK
Files we need PCB: Gerber files(CAM, PCB, PCBDOC)
Components: Bill of Materials(BOM list)
Assembly: Pick-N-Place file
PCB panel Size Min size: 0.25*0.25 inches(6*6mm)
Max size: 20*20 inches(500*500mm)
PCB Solder Type Water Soluble Solder Paste, RoHS lead free
Components details Passive Down to 0201 size
BGA and VFBGA
Leadless Chip Carriers/CSP
Double-sided SMT Assembly
Fine Pitch to 0.8mils
BGA Repair and Reball
Part Removal and Replacement
Component package Cut Tape,Tube,Reels,Loose Parts
PCBA process

Drilling-----Exposure-----Plating-----Etaching

Stripping-----Punching-----Electrical Testing-----SMT-----Wave

Soldering-----Assembling-----ICT-----Function Testing-----Temperature - Humidity Testing


PCB&PCBA Products Show

6oz PCB Circuit Board 9

6oz PCB Circuit Board 10

6oz PCB Circuit Board 11



Company Certifications

6oz PCB Circuit Board 12

Packaging & Shipping

Packing details:

PCBA are packed into plastic bags. Plastic bags are put into small carton. 4 small carton into a big carton.

A big carton: 35×32×40 cm size.

Shipping Express:

FedEx, DHL, UPS, TNT, EMS, private lines, etc.

Air freight, Sea shipping

6oz PCB Circuit Board 13

If you need help on PCB layout, you can contact us and send the board to us. We also provide Reverse Engineering Service.

We have been providing PCB Manufacture for many years in China,and we have rich experience in product production and product assembly.We believe our team will provide high quality and low cost service for you.

Thank you very much for all your support .

Best Regareds.

AFQ:

Q:Are you manufacturer?
A:Yes we are manufacturer

Q:Do you provide samples?
A:Yes we can provide free samples,price and shipping cost open for negotiation

Q:How do you ensure the quality of your products
A:We will burn into file and test the product and ship it after confirming that there is no problem

Q:What certificates does this product have
A:We have CE,FCC,ROHS certified

Q:What about OEM and ODM?
A:We accept OEM and ODM orders,MOQ is open for discussion

Q:What is delivery terms and time?
A:We use FOB terms and ship the goods in 7-30days depend on your order quanlity,customization
