CEM-3 PCBA Manufacturing PCB Assembly Circuit Board 3mil For Customer Service

1PCS
MOQ
USD+0.1-1+per pcs
Price
CEM-3 PCBA Manufacturing PCB Assembly Circuit Board 3mil For Customer Service
Features Gallery Product Description Request A Quote
Features
Specifications
Place Of Origin:: Guangdong, China
Brand Name:: OEM / ODM
Base Material:: FR-4/High TG FR-4/CEM-3/CEM-1
Copper Thickness:: HOZ-6OZ
Board Thickness:: 0.2mm-6mm(8mil-126mil)
Min. Hole Size:: 0.15mm
Min. Line Width:: 3mil
Surface Finishing:: LF-HAL,HASL,gold
Layer:: 1-24 Layers
Solder Mask Color:: White Black Yellow Green Red
MOQ:: 1PCS
High Light:

PCB Assembly Circuit Board 3mil

,

PCB Board Manufacturing CEM-3

,

CEM-3 PCB Assembly Circuit Board

Basic Infomation
Place of Origin: Guangdong, China
Brand Name: GW-PCBA
Certification: ISO9001, ISO14001, TS16949, ROHS, CE
Model Number: Custom part number of each design
Payment & Shipping Terms
Packaging Details: PCB: Vacuum Packing with Carton Box PCBA: ESD Packing with Carton Box
Delivery Time: PCB 3-7dyas, PCBA 1-3weeks/1 - 1000 -15days;1001 - 5000-20days;5001 - 20000-35days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 30000 Square Meter/Square Meters per Month module electronic board
Product Description

PCBA Manufacturing PCB Assembly Circuit Board Factory For Customer Service

Turnkey PCB AssemblyIntroduction

Turnkey PCB assembly is a manufacturing process that starts with the initial design and ends with delivering a fully functional circuit board to the OEM’s end-user. Our full turnkey services handle all aspects of circuit board manufacturing, including shipping the final product in your company’s packing materials. Not only does this get the completed circuit boards to your end-users faster, but it will also reduce your processing overhead.



Our advantage

Service value

Independent quotation system to quickly serve the market



PCB manufacturing

High-tech PCB and PCB assembly production line



Material purchasing

A team of experienced electronic component procurement engineers



SMT post soldering

Dust-free workshop, high-end SMT patch processing

Our Services

1. PCB fabrication.

2. Turnkey PCBA: PCB+components sourcing+SMD and through-hole assembly

3. PCB clone, PCB reverse engineering.
CEM-3 PCBA Manufacturing PCB Assembly Circuit Board 3mil For Customer Service 0
PCB or PCBA Files Requests:


1. Gerber files of the bare PCB board
2. BOM (Bill of material) for assembly (please kindly advise us if there is any acceptablecomponents substitution.)
3. Testing Guide & Test Fixtures if necessary
4. Programming files & Programming tool if necessary
5. Schematic if necessary

CEM-3 PCBA Manufacturing PCB Assembly Circuit Board 3mil For Customer Service 1

Company Information

Global Well Electronic Inc. is a professional PCB solution supplier from Shenzhen, China, integrating PCB circuit board production and processing, STM processing and mounting, PCBA OEM, component purchasing, PCB/PCBA custom design-production- A comprehensive PCB circuit board company with one-stop turnkey service of processing-assembly-finished products. The company has a strong supply chain system, a professional and efficient collaborative team, a sound and complete quality control system, and the business philosophy of honesty and trustworthiness, customer first, and presents the products to everyone with low prices, reliable quality, high-quality service and after-sales service. client.

We provide total PCB solutions from PCB design to final mass production, including PCB fabrication and assembly, component sourcing, solder paste stencils, conformal coatings, and more. Serving the global electronics field, including industrial control, medical electronics, military equipment, power communication, automotive electronics, AI artificial intelligence, smart home and other industries.

CEM-3 PCBA Manufacturing PCB Assembly Circuit Board 3mil For Customer Service 2

CEM-3 PCBA Manufacturing PCB Assembly Circuit Board 3mil For Customer Service 3

Our factory located in Shenzhen, and have almost 300 employees, more than 30 production lines include SMT, DIP, automatic welding, aging test and assembly. We have SMT machines from Japan and Korea, automatic solder paste printing machines, solder paste inspection machine(SPI)12 temperature zone reflow soldering machine, AOI detector, X-RAY detector, wave soldering machine, EM PCB ,dispenser,laser print machine etc., Different line configurations can meet requirements from small sample order to bulk shipment.

Our company has obtained ISO 9001 quality system certification and ISO 14001 system certification. With multi-testingprocedures, our products carry out the quality system standard strictly.

Main Equipment:

CEM-3 PCBA Manufacturing PCB Assembly Circuit Board 3mil For Customer Service 4

CEM-3 PCBA Manufacturing PCB Assembly Circuit Board 3mil For Customer Service 5

CEM-3 PCBA Manufacturing PCB Assembly Circuit Board 3mil For Customer Service 6



PCB Technical Specification

(1) PCB Technical Specification

Order Quantity 1-300,000,30000 Square Meter/Square Meters per Month module electronic board
Layer 1,2,4,6,upto 40 layer
Material FR-4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc
PCB type Rigid,flexible,rigid-flexible
Shape Any shape: Rectangular,round,slots,cutouts,complex,irregular
Max PCB dimensions 20inch*20inch or 500mm*500mm
Thickness 0.2~4.0mm, Flex 0.01~0.25''
Thickness tolerance ± 10%
Copper thickness 0.5-4 oz
Copper thickness tolerance ± 0.25oz
Surface finish HASL,Nickle,Imm Gold,Imm Tin,Imm Silver,OSP etc
Solder mask Green, red,white,yellow,blue,black, Double-sided
Silk screen White,yellow,black,or negative, Double-sided or single-sided
Silk screen min line width 0.006'' or 0.15mm
Min drill hole diameter 0.01'',0.25mm.or 10 mil
Min trace/gap 0.075mm or 3mil
PCB cutting Shear,V-score,tab-routed

(2) Turnkey PCBA Capabilities

Turnkey PCBA PCB+components sourcing+assembly+package
Assembly details SMT and Thru-hole, ISO lines
Lead Time Prototype: 15 work days. Mass order: 20~25 work days
Testing on products Flying Probe Test, X-ray Inspection, AOI Test, functional test
Quantity Min quantity: 1pcs. Prototype, small order, mass order, all OK
Files we need PCB: Gerber files(CAM, PCB, PCBDOC)
Components: Bill of Materials(BOM list)
Assembly: Pick-N-Place file
PCB panel Size Min size: 0.25*0.25 inches(6*6mm)
Max size: 20*20 inches(500*500mm)
PCB Solder Type Water Soluble Solder Paste, RoHS lead free
Components details Passive Down to 0201 size
BGA and VFBGA
Leadless Chip Carriers/CSP
Double-sided SMT Assembly
Fine Pitch to 0.8mils
BGA Repair and Reball
Part Removal and Replacement
Component package Cut Tape,Tube,Reels,Loose Parts
PCBA process

Drilling-----Exposure-----Plating-----Etaching

Stripping-----Punching-----Electrical Testing-----SMT-----Wave

Soldering-----Assembling-----ICT-----Function Testing-----Temperature - Humidity Testing


PCB&PCBA Products Show

CEM-3 PCBA Manufacturing PCB Assembly Circuit Board 3mil For Customer Service 7

CEM-3 PCBA Manufacturing PCB Assembly Circuit Board 3mil For Customer Service 8

Certifications

CEM-3 PCBA Manufacturing PCB Assembly Circuit Board 3mil For Customer Service 9

Packaging & Shipping

Packing details:

PCBA are packed into plastic bags. Plastic bags are put into small carton. 4 small carton into a big carton.

A big carton: 35×32×40 cm size.

Shipping Express:

FedEx, DHL, UPS, TNT, EMS, private lines, etc.

Air freight, Sea shipping

CEM-3 PCBA Manufacturing PCB Assembly Circuit Board 3mil For Customer Service 10

If you need help on PCB layout, you can contact us and send the board to us. We also provide Reverse Engineering Service.

We have been providing PCB Manufacture for many years in China,and we have rich experience in product production and product assembly.We believe our team will provide high quality and low cost service for you.

Thank you very much for all your support .

Best Regareds.
