Professional FPC PCB Electronic Circuit Board Assembly Rigid-Flex PCB Manufacturing

Rigid Flex Printed Circuit Board Manufacturer: What We Offer

Rigid flex printed circuit boards (PCBs) are manufactured by combining rigid and flexible board technologies. These circuit boards are made up of multiple flexible circuit inner layers. An epoxy pre-preg bonding film is used to attach together these inner layers. The key benefit of these boards is that they are a combination of the best quality of flexible and rigid circuit boards. This can have several further benefits as far as stability, assembly, signal transmission, and overall size of the circuit are concerned. Rigiflex Technologies provides a number of variants in rigid flex PCBs, which include 4 layer rigid-flex with ENIG finish, 10 layer rigid-flex with 4 layer flex, 12 layer rigid-flex with heat sink, 14 layer rigid flex circuit boards, and many more. It is one of the leading rigid flex PCB manufacturers.

0.5mm Flexible PCB Fabrication 24 Layers 0

Rigid-Flex PCB Capabilities of Rigiflex

At Rigiflex, you get to choose from a vast variety of rigid-flex printed circuit boards. We provide rigid-flex circuit boards in a wide range of capabilities and specifications. Following are the capabilities of rigid-flex circuit boards available with us:

Standard Panel Size 18″x24″
Copper Thickness 0.5 oz. To 6.0 oz.
Board Thickness 0.5mm~3.0mm (0.02″~0.12″)
Minimum Height 25 mil (0.64 mm)
Minimum Width 6 mil (0.15 mm)
Solder Mask White, Black, Blue, Green, Red
Legend/Silkscreen Color Black, White
Surface Finishing Immersion Gold, HASL, OSP
Layer 1-40 Layers
Standards

MIL-PRF-55110, MIL-PRF-50884, MIL-PRF-31032

UL94V.0, IPC-6012,6013, ISO-9001, AS910

Turnaround Times Multilayers: 1 to 5 days
Minimum Drill (Mechanical) Hole Diameter .006″ (0.15 mm)
Minimum Micro Via (Laser) Size 1 mil (0.025 mm)
Minimum Via (Laser) Size 1 mil (0.025 mm)
Shielding Material Copper, Silver Ink, Tatsuta, Carbon

Company Information

Global Well Electronic Inc. is a professional PCB solution supplier from Shenzhen, China, integrating PCB circuit board production and processing, STM processing and mounting, PCBA OEM, component purchasing, PCB/PCBA custom design-production- A comprehensive PCB circuit board company with one-stop turnkey service of processing-assembly-finished products. The company has a strong supply chain system, a professional and efficient collaborative team, a sound and complete quality control system, and the business philosophy of honesty and trustworthiness, customer first, and presents the products to everyone with low prices, reliable quality, high-quality service and after-sales service. client.

We provide total PCB solutions from PCB design to final mass production, including PCB fabrication and assembly, component sourcing, solder paste stencils, conformal coatings, and more. Serving the global electronics field, including industrial control, medical electronics, military equipment, power communication, automotive electronics, AI artificial intelligence, smart home and other industries.

0.5mm Flexible PCB Fabrication 24 Layers 1

0.5mm Flexible PCB Fabrication 24 Layers 2

Our factory located in Shenzhen, and have almost 300 employees, more than 30 production lines include SMT, DIP, automatic welding, aging test and assembly. We have SMT machines from Japan and Korea, automatic solder paste printing machines, solder paste inspection machine(SPI)12 temperature zone reflow soldering machine, AOI detector, X-RAY detector, wave soldering machine, EM PCB ,dispenser,laser print machine etc., Different line configurations can meet requirements from small sample order to bulk shipment.

Our company has obtained ISO 9001 quality system certification and ISO 14001 system certification. With multi-testingprocedures, our products carry out the quality system standard strictly.



Our Services

1. PCB fabrication.

2. Turnkey PCBA: PCB+components sourcing+SMD and through-hole assembly

3. PCB clone, PCB reverse engineering.
0.5mm Flexible PCB Fabrication 24 Layers 3
PCB or PCBA Files Requests:


1. Gerber files of the bare PCB board
2. BOM (Bill of material) for assembly (please kindly advise us if there is any acceptablecomponents substitution.)
3. Testing Guide & Test Fixtures if necessary
4. Programming files & Programming tool if necessary
5. Schematic if necessary

0.5mm Flexible PCB Fabrication 24 Layers 4

PCB Technical Specification

(1) PCB Technical Specification

Order Quantity 1-300,000,30000 Square Meter/Square Meters per Month module electronic board
Layer 1,2,4,6,upto 40 layer
Material FR-4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc
PCB type Rigid,flexible,rigid-flexible
Shape Any shape: Rectangular,round,slots,cutouts,complex,irregular
Max PCB dimensions 20inch*20inch or 500mm*500mm
Thickness 0.2~4.0mm, Flex 0.01~0.25''
Thickness tolerance ± 10%
Copper thickness 0.5-4 oz
Copper thickness tolerance ± 0.25oz
Surface finish HASL,Nickle,Imm Gold,Imm Tin,Imm Silver,OSP etc
Solder mask Green, red,white,yellow,blue,black, Double-sided
Silk screen White,yellow,black,or negative, Double-sided or single-sided
Silk screen min line width 0.006'' or 0.15mm
Min drill hole diameter 0.01'',0.25mm.or 10 mil
Min trace/gap 0.075mm or 3mil
PCB cutting Shear,V-score,tab-routed

(2) Turnkey PCBA Capabilities

Turnkey PCBA PCB+components sourcing+assembly+package
Assembly details SMT and Thru-hole, ISO lines
Lead Time Prototype: 15 work days. Mass order: 20~25 work days
Testing on products Flying Probe Test, X-ray Inspection, AOI Test, functional test
Quantity Min quantity: 1pcs. Prototype, small order, mass order, all OK
Files we need PCB: Gerber files(CAM, PCB, PCBDOC)
Components: Bill of Materials(BOM list)
Assembly: Pick-N-Place file
PCB panel Size Min size: 0.25*0.25 inches(6*6mm)
Max size: 20*20 inches(500*500mm)
PCB Solder Type Water Soluble Solder Paste, RoHS lead free
Components details Passive Down to 0201 size
BGA and VFBGA
Leadless Chip Carriers/CSP
Double-sided SMT Assembly
Fine Pitch to 0.8mils
BGA Repair and Reball
Part Removal and Replacement
Component package Cut Tape,Tube,Reels,Loose Parts
PCBA process

Drilling-----Exposure-----Plating-----Etaching

Stripping-----Punching-----Electrical Testing-----SMT-----Wave

Soldering-----Assembling-----ICT-----Function Testing-----Temperature - Humidity Testing



Main Equipment:

0.5mm Flexible PCB Fabrication 24 Layers 5

0.5mm Flexible PCB Fabrication 24 Layers 6

0.5mm Flexible PCB Fabrication 24 Layers 7



PCB&PCBA Products Show

0.5mm Flexible PCB Fabrication 24 Layers 8

0.5mm Flexible PCB Fabrication 24 Layers 9

Certifications

0.5mm Flexible PCB Fabrication 24 Layers 10

Packaging & Shipping

Packing details:

PCBA are packed into plastic bags. Plastic bags are put into small carton. 4 small carton into a big carton.

A big carton: 35×32×40 cm size.

Shipping Express:

FedEx, DHL, UPS, TNT, EMS, private lines, etc.

Air freight, Sea shipping

0.5mm Flexible PCB Fabrication 24 Layers 11

If you need help on PCB layout, you can contact us and send the board to us. We also provide Reverse Engineering Service.
