8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype

1PCS
MOQ
USD+0.01-10+per pcs
Price
8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype
Features Gallery Product Description Request A Quote
Features
Specifications
Base Material: FR4 CEM1 CEM3 Ceramic Aluminum
Min. Line Spacing: 0.1mm/4mil
Min. Hole Size: 0.1mm-1mm
Surface Finishing: HASL,Gold Plating
Product Name: Electronic Boards
Solder Mask: Green. Red. Blue. White. Black.Yellow
Application: Consumer Electronics
Material: FR4 CEM1 CEM3 Hight TG
Solder Mask Color: Green Black Red
Service: OEM/ODM
Layer: 1-40 Layer
Type: Customizable
Test: E-test/Fixture Test/Functional Test
Usage: OEM Electronics
High Light:

8 Layers Multilayer PCB Fabrication

,

Multilayer PCB Fabrication 1mm

,

1mm Fabrication PCB Prototype

Basic Infomation
Place of Origin: Guangdong, China
Brand Name: GW-PCBA
Certification: ISO9001/Iso14001/CE/ROHS
Model Number: PCBA-1501
Payment & Shipping Terms
Packaging Details: PCB: Vacuum Packing with Carton Box PCBA: ESD Packing with Carton Box
Delivery Time: PCB 3-7dyas, PCBA 1-3weeks
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 30000 Square Meter/Square Meters per Month module electronic board
Product Description

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype

Multilayer PCB

The layer count of PCB determines its manufacturing technology difficulty and PCB manufacturing cost. PCB boards can be briefly classified into two categories: single-layer (single-sided) PCB and double-layer (double-sided) PCB. When it comes to high-end electronic products, a couple of signal layers can be added to the inside of PCB apart from surface routing due to some limitations in terms of board real estate and board design. During the manufacturing procedure, after routing for each layer has been finished with positioning and lamination completed, multiple layers of signals will be pressed into a single board that is called multilayer PCB. Therefore, a multilayer PCB refers to any piece of circuit board containing more than two layers of signals. Multilayer PCBs can be multilayer rigid PCB, multilayer flex PCB and flex-rigid multilayer PCB.

Necessity of Multilayer PCB

Due to the increasing use of IC (Integrated Circuit) package, interconnection lines become so dense that multi-substrate boards become necessary. In addition, some design problems, like noise, stray capacitance, crosstalk etc., are so protruding that should be solved through multilayer resolution. As a result, multilayer PCB design has to make sure that signal lines should be minimized and parallel circuits should be avoided, which is apparently difficult to be obtained in either single-sided or double-sided design. Therefore, multilayer printed circuit boards come into being for the acquisition of perfect performance of circuits.



The original aim of multilayer PCB is to provide more freedom in terms of routing for circuits that are complex and/or sensitive to noise. There are at least three layers in a multi layer circuit board and two layers are external with the left layer(s) synthesized inside insulating plate. The electrical connection in a multilayer PCB derives from plated through hole on the cross section of circuit board.

Advantages of Multilayer PCB

• Smaller size
• Lower weight
• Higher speed of signal transmission
• Constantly low impedance
• Better shielding effect
• Higher assembly density

Item Capability
Material FR4 Tg 140C/150C
FR4 High Tg 170C/180C
FR4 Halogen-Free
FR4 Halogen-Free & High Tg
Board Type Multilayer Rigid PCB
Multilayer Flex PCB
Rigid-Flex Multilayer PCB
Layer Count 1-32layers
Board Dimension 6mm*6mm - 600mm*700mm
Board Thickness 0.6mm - 3.2mm
Copper Weight 0.5oz - 6oz
Min. Spacing/Tracing 3mil/3mil
Surface Finish HASL (lead & lead-free)
ENIG
Immersion Silver/Tin
OSP
Min. Annular Ring 3mil
Aspect Ratio 10:1
Min. Drilling Hole Diameter 6mil, 4mil (laser drill)
Other Techniques Blind/Buried Via
Gold Fingers
Press Fit
Via in Pad
Electrical Test

Multilayer PCB boards can be served in so many industries including consumer electronics, medical care, aerospace, telecommunications, military, automotive, wearables, IoT etc. based on its benefits. PCBCart has been striving to provide high-quality multilayer PCBs for customers with full concerns in terms of design, cost and lead time. Contact us to find reliable experts of multilayer PCB manufacturing!



Service Advantages

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 0

Quality Advantages

①.Make full preparations before SMT Assembly Prepare relevant product process documents; Receive materials (PCB, Components) according to the mounting details of product process documents and check them; Baking treatment shall be carried out according to the shelf life of PCB, the length of unsealing time, Components characteristics and whether it is affected by moisture.

②.Inspection during SMT Assembly Perform product quality inspection during SMT assembly using precision equipment such as AOI, X-RAY, ICT equipment.Ensure the quality of assembly process is up to standard.

③.Conduct inspection of the Assembled products The First Article shall be sent to the special inspection after passing the self inspection, and then pasted in mass production after passing the special inspection.



ITEM Capacity



Assembly Component Specification

Min. IC Pitch 03015 Chip/0.35 Pitch BGA
Minimum Component accuracy ±0.04mm
IC assembly precision ±0.03mm



PCB Specification

PCB size 50*50mm - 774*710mm
PCB Thickness 0.3-6.5mm
ITEM Capacity
SMT Production Capacity 8.5 million solder joints per day
SMT Production Line 8



SMT Material Throw Rate

The scrap rate of resistance and capacitance is 0.3%
IC no scrap
Machined PCB Type POP/ Normal PCB /FPC/ Rigid-flex /metal substrate





8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 1

Our Services

1. PCB fabrication.

2. Turnkey PCBA: PCB+components sourcing+SMD and through-hole assembly

3. PCB clone, PCB reverse engineering.
8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 2
8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 3

Company Information

Global Well Electronic Inc. is a professional PCB solution supplier from Shenzhen, China, integrating PCB circuit board production and processing, STM processing and mounting, PCBA OEM, component purchasing, PCB/PCBA custom design-production- A comprehensive PCB circuit board company with one-stop turnkey service of processing-assembly-finished products. The company has a strong supply chain system, a professional and efficient collaborative team, a sound and complete quality control system, and the business philosophy of honesty and trustworthiness, customer first, and presents the products to everyone with low prices, reliable quality, high-quality service and after-sales service. client.

We provide total PCB solutions from PCB design to final mass production, including PCB fabrication and assembly, component sourcing, solder paste stencils, conformal coatings, and more. Serving the global electronics field, including industrial control, medical electronics, military equipment, power communication, automotive electronics, AI artificial intelligence, smart home and other industries.

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 4

Our factory located in Shenzhen, and have almost 300

employees, more than 30 production lines include SMT, DIP, automatic welding, aging test and assembly. We have SMT machines from Japan and Korea, automatic solder paste printing machines, solder paste inspection machine(SPI)12 temperature zone reflow soldering machine, AOI detector, X-RAY detector, wave soldering machine, EM PCB ,dispenser,laser print machine etc., Different line configurations can meet requirements from small sample order to bulk shipment.

Our company has obtained ISO 9001 quality system certification and ISO 14001 system certification. With multi-testingprocedures, our products carry out the quality system standard strictly.

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 5

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 6

Main Equipment:

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 7

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 8

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 9

Company Capability

(1)PCB Technical Specification

Order Quantity 1-300,000,30000 Square Meter/Square Meters per Month module electronic board
Layer 1,2,4,6,upto 24 layer
Material FR-4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc
PCB type Rigid,flexible,rigid-flexible
Shape Any shape: Rectangular,round,slots,cutouts,complex,irregular
Max PCB dimensions 20inch*20inch or 500mm*500mm
Thickness 0.2~4.0mm, Flex 0.01~0.25''
Thickness tolerance ± 10%
Copper thickness 0.5-4 oz
Copper thickness tolerance ± 0.25oz
Surface finish HASL,Nickle,Imm Gold,Imm Tin,Imm Silver,OSP etc
Solder mask Green, red,white,yellow,blue,black, Double-sided
Silk screen White,yellow,black,or negative, Double-sided or single-sided
Silk screen min line width 0.006'' or 0.15mm
Min drill hole diameter 0.01'',0.25mm.or 10 mil
Min trace/gap 0.075mm or 3mil
PCB cutting Shear,V-score,tab-routed

(2)Turnkey PCBA Capabilities

Turnkey PCBA PCB+components sourcing+assembly+package
Assembly details SMT and Thru-hole, ISO lines
Lead Time Prototype: 15 work days. Mass order: 20~25 work days
Testing on products Flying Probe Test, X-ray Inspection, AOI Test, functional test
Quantity Min quantity: 1pcs. Prototype, small order, mass order, all OK
Files we need PCB: Gerber files(CAM, PCB, PCBDOC)
Components: Bill of Materials(BOM list)
Assembly: Pick-N-Place file
PCB panel Size Min size: 0.25*0.25 inches(6*6mm)
Max size: 20*20 inches(500*500mm)
PCB Solder Type Water Soluble Solder Paste, RoHS lead free
Components details Passive Down to 0201 size
BGA and VFBGA
Leadless Chip Carriers/CSP
Double-sided SMT Assembly
Fine Pitch to 0.8mils
BGA Repair and Reball
Part Removal and Replacement
Component package Cut Tape,Tube,Reels,Loose Parts
PCBA process

Drilling-----Exposure-----Plating-----Etaching

Stripping-----Punching-----Electrical Testing-----SMT-----Wave

Soldering-----Assembling-----ICT-----Function Testing-----Temperature - Humidity Testing


PCB&PCBA Products Show

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 10

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 11

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 12

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 13

Company Certifications

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 14

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 15

Packaging & Shipping

Packing details:

PCBA are packed into plastic bags. Plastic bags are put into small carton. 4 small carton into a big carton.

A big carton: 35×32×40 cm size.

Shipping Express:

FedEx, DHL, UPS, TNT, EMS, private lines, etc.

Air freight, Sea shipping

8 Layers Multilayer PCB Fabrication 1mm Fabrication PCB Prototype 16

If you need help on PCB layout, you can contact us and send the board to us. We also provide Reverse Engineering Service.

We have been providing PCB Manufacture for many years in China,and we have rich experience in product production and product assembly.We believe our team will provide high quality and low cost service for you.

Thank you very much for all your support .

Best Regareds.



PCB or PCBA Files Requests:

1. Gerber files of the bare PCB board
2. BOM (Bill of material) for assembly (please kindly advise us if there is any acceptablecomponents substitution.)
3. Testing Guide & Test Fixtures if necessary
4. Programming files & Programming tool if necessary
5. Schematic if necessary

FAQ:

Q: What files do you use in PCBA fabrication?

A: Gerber or Eagle, BOM listing, PNP and Components Position

Q:Is it possible you could offer sample?

A: Yes, we can custom you sample to test before mass production

Q: When will I get the quotation after sent Gerber, BOM and test procedure?

A: Within 6 hours for PCB quotation and around 24 hours for PCBA quotation.

Q: How can I know the process of my PCBA production?

A: 7-10 days for PCB production and components purchasing, and 10 days for PCB assembly and Testing

Q: How can I make sure the quality of my PCBA?
A: We ensure that each piece of PCBA products work well before shipping. We'll test all of them according to your test procedure. Also if there are any defect items during the shipping, we also can be free to repair for you.
